|PMT管径||38 mm (1-1/2) mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[絶対最大定格] 陽極－陰極間電圧||-1750 V|
|[絶対最大定格] デバイダ電流||0.63 mA|
|陽極－陰極間 印加電圧||-1500 V|
|[陰極特性] ルーメン感度 Typ.||95 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陽極特性] ルーメン感度 Typ.||75 A/lm|
|[陽極特性] ゲイン Typ.||7.9 x 105|
|[陽極特性] 暗電流(30分後) Typ.||2 nA|
|[陽極特性] 暗電流(30分後) Max.||15 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2.7 ns|
|[時間特性] 走行時間 (T.T.) Typ.||40 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||4.5 ns|
|[陽極特性] パルスリニアリティ （2%変動）||150 mA|
|[陽極特性] パルスリニアリティ （5%変動）||200 mA|
