|PMT管径||25 mm (1) mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[絶対最大定格] 陽極－陰極間電圧||-2500 V|
|[絶対最大定格] デバイダ電流||0.36 mA|
|陽極－陰極間 印加電圧||-2250 V|
|[陰極特性] ルーメン感度 Typ.||80 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||9.5|
|[陽極特性] ルーメン感度 Typ.||400 A/lm|
|[陽極特性] ゲイン Typ.||5.7 x 106|
|[陽極特性] 暗電流(30分後) Typ.||100 nA|
|[陽極特性] 暗電流(30分後) Max.||200 nA|
|[時間特性] 上昇時間 (Tr) Typ.||0.7 ns|
|[時間特性] 走行時間 (T.T.) Typ.||10 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||0.16 ns|
|[陽極特性] パルスリニアリティ （2%変動）||40 mA|
|[陽極特性] パルスリニアリティ （5%変動）||70 mA|
