|PMT管径||19 mm (3/4) mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[絶対最大定格] 陽極－陰極間電圧||-1800 V|
|[絶対最大定格] デバイダ電流||0.35 mA|
|陽極－陰極間 印加電圧||-1700 V|
|[陰極特性] ルーメン感度 Typ.||115 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陽極特性] ルーメン感度 Typ.||200 A/lm|
|[陽極特性] ゲイン Typ.||1.7 x 106|
|[陽極特性] 暗電流(30分後) Typ.||10 nA|
|[陽極特性] 暗電流(30分後) Max.||300 nA|
|[時間特性] 上昇時間 (Tr) Typ.||1.3 ns|
|[時間特性] 走行時間 (T.T.) Typ.||14 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||0.36 ns|
|[陽極特性] パルスリニアリティ （2%変動）||4 mA|
|[陽極特性] パルスリニアリティ （5%変動）||8 mA|
