|感度波長 (Short)||300 nm|
|感度波長 (Long)||900 nm|
|感度波長 (Peak)||600 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.2 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||120 μA/lm|
|[陰極特性] ルーメン感度 Typ.||200 μA/lm|
|[陰極特性] 赤感度比 （R-68） Typ.||0.3|
|[陰極特性] 放射感度 Typ.||40 mA/W|
|[陽極特性] ルーメン感度 Min.||20 A/lm|
|[陽極特性] ルーメン感度 Typ.||50 A/lm|
|[陽極特性] 放射感度 Typ.||1.0 x 104 A/W|
|[陽極特性] ゲイン Typ.||2.5 x 105|
|[陽極特性] 暗電流(30分後) Typ.||8 nA|
|[陽極特性] 暗電流(30分後) Max.||30 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2.8 ns|
|[時間特性] 走行時間 (T.T.) Typ.||40 ns|
