|受光面サイズ||5 x 8 mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.01 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||30 μA/lm|
|[陰極特性] ルーメン感度 Typ.||50 μA/lm|
|[陰極特性] 放射感度 Typ.||50 mA/W|
|[陽極特性] ルーメン感度 Min.||100 A/lm|
|[陽極特性] ルーメン感度 Typ.||300 A/lm|
|[陽極特性] 放射感度 Typ.||3.0 x 105 A/W|
|[陽極特性] ゲイン Typ.||6.0 x 106|
|[時間特性] 上昇時間 (Tr) Typ.||13 ns|
|[時間特性] 走行時間 (T.T.) Typ.||70 ns|
|備考||陽極ダークカウント(Typ.) ：5 (s-1) 陽極ダークカウント(Max.) : 15 (s-1)|
