|受光面サイズ||3 x 8 mm|
|感度波長 (Short)||300 nm|
|感度波長 (Long)||1400 nm|
|感度波長 (Peak)||1300 nm|
|[最大定格] 陽極－陰極間電圧||1750 V|
|[最大定格] 平均陽極電流||0.002 mA|
|陽極－陰極間 印加電圧||1500 V|
|[陰極特性] 放射感度 Typ.||5 mA/W|
|[陽極特性] 放射感度 Typ.||1000 A/W|
|[陽極特性] ゲイン Typ.||1.0 x 106|
|[陽極特性] 暗電流(30分後) Typ.||4 nA|
|[陽極特性] 暗電流(30分後) Max.||10 nA|
|[時間特性] 上昇時間 (Tr) Typ.||3 ns|
|[時間特性] 走行時間 (T.T.) Typ.||23 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||1.5 ns|
