|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||70 μA/lm|
|[陰極特性] ルーメン感度 Typ.||95 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陰極特性] 放射感度 Typ.||88 mA/W|
|[陽極特性] ルーメン感度 Min.||50 A/lm|
|[陽極特性] ルーメン感度 Typ.||250 A/lm|
|[陽極特性] 放射感度 Typ.||2.3 x 105 A/W|
|[陽極特性] ゲイン Typ.||2.6 x 106|
|[陽極特性] 暗電流(30分後) Typ.||2 nA|
|[陽極特性] 暗電流(30分後) Max.||15 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2.5 ns|
|[時間特性] 走行時間 (T.T.) Typ.||28 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||1.2 ns|
|[陽極特性] パルスリニアリティ （2%変動）||5 mA|
|[陽極特性] パルスリニアリティ （5%変動）||8 mA|
