|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1250 V|
|[陰極特性] ルーメン感度 Min.||60 μA/lm|
|[陰極特性] ルーメン感度 Typ.||95 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陰極特性] 放射感度 Typ.||88 mA/W|
|[陽極特性] ルーメン感度 Min.||20 A/lm|
|[陽極特性] ルーメン感度 Typ.||40 A/lm|
|[陽極特性] 放射感度 Typ.||3.7 x 104 A/W|
|[陽極特性] ゲイン Typ.||4.2 x 105|
|[陽極特性] 暗電流(30分後) Typ.||10 nA|
|[陽極特性] 暗電流(30分後) Max.||50 nA|
|[時間特性] 上昇時間 (Tr) Typ.||20 ns|
|[時間特性] 走行時間 (T.T.) Typ.||115 ns|
