|受光面サイズ||3 x 12 mm|
|感度波長 (Short)||185 nm|
|感度波長 (Long)||1010 nm|
|感度波長 (Peak)||400 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.001 mA|
|陽極－陰極間 印加電圧||1250 V|
|[陰極特性] ルーメン感度 Min.||50 μA/lm|
|[陰極特性] ルーメン感度 Typ.||100 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||4.5|
|[陰極特性] 赤感度比 （R-68） Typ.||0.4|
|[陰極特性] 放射感度 Typ.||1 (at 1um) mA/W|
|[陽極特性] ルーメン感度 Min.||5 A/lm|
|[陽極特性] ルーメン感度 Typ.||16 A/lm|
|[陽極特性] 放射感度 Typ.||1.6 x 102 A/W|
|[陽極特性] ゲイン Typ.||1.6 x 105|
|[陽極特性] 暗電流(30分後) Typ.||1 nA|
|[陽極特性] 暗電流(30分後) Max.||10 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2 ns|
|[時間特性] 走行時間 (T.T.) Typ.||20 ns|
