|最大入力電流||+6.5 / -3.5 mA|
|[PMT] 直線出力電流 Min.||40（負荷抵抗 10 kΩ時） μA|
|[高圧電源] 出力電圧範囲||0 ～ -1500 V|
|[高圧電源] 入力変動率（±1 V入力変動） Typ.||±0.01 %|
|[高圧電源] 出力電圧コントロール||0 V ～ +1.5 Vまたは10 kΩポテンショメータ|
|[高圧電源] セトリングタイム||10 s|
|[高圧電源] 温度係数 Typ.||±0.01 %/℃|
|[アンプ] 周波数帯域 (-3 dB)||DC ～ 200 kHz|
|[アンプ] 電流電圧変換係数||0.1（負荷抵抗 10 kΩ時） V/uA|
|[アンプ] 最大出力信号電圧||+4（負荷抵抗 10 kΩ時） V|
|[アンプ] 信号出力オフセット電圧 Typ.||±1 mV|
|[アンプ] 信号出力リップル/ノイズ||1 mVp-p (Max.)|
|動作周囲温度||0 ～ +50 ℃|
|保存温度||-15 ～ +60 ℃|
|質量 Typ.||180 ｇ|
