|入力電圧||+15 V ±1 V|
|[PMT] 直線出力電流 Min.||100 μA|
|[PMT] 出力信号 リップル/ノイズ Typ.||0.5 ｍVp-p|
|[高圧電源] 出力電圧範囲||0 V ～ -1500 V|
|[高圧電源] 推奨出力電圧範囲||-200 V ～ -1500 V|
|[高圧電源] 入力変動率（±1 V入力変動） Typ.||±0.01 %|
|[高圧電源] 出力電圧コントロール||0 V ～ +6 V または ポテンショメータ (50 kΩ)|
|[高圧電源] 推奨コントロール電圧範囲||+0.8 V ～ +6 V|
|[高圧電源] コントロール電圧入力インピーダンス||100 kΩ|
|[高圧電源] 温度係数 Typ.||±0.01 %/℃|
|動作周囲温度||0 ℃ ～ +45 ℃|
|保存温度||-15 ℃ ～ +60 ℃|
|質量 Typ.||122 ｇ|
