|適合PMT||28 mm ヘッドオン型|
|[PMT] 直線出力電流 Min.||100 μA|
|[PMT] 出力信号 リップル/ノイズ Typ.||0.5 ｍVp-p|
|[高圧電源] 出力電圧範囲||-200 ～ -1500 V|
|[高圧電源] 入力変動率（±1 V入力変動） Typ.||±0.01 %|
|[高圧電源] 出力電圧コントロール||0 V ～ +6 Vまたは50 kΩポテンショメータ|
|[高圧電源] 出力電圧応答 Typ.||80 ms|
|[高圧電源] 温度係数 Typ.||±0.01 %/℃|
|動作周囲温度||0 ～ +40 ℃|
|保存温度||-15 ～ +60 ℃|
|質量 Typ.||40 ｇ|
