|入力電圧||+11.5 ～ +15.5||V|
|最大コントロール電圧||+0.9 (入力インピーダンス 30kΩ)||V|
|推奨コントロール電圧調整範囲||+0.5 ～ +0.8||V|
|感度波長範囲||380 ～ 900||nm|
|at 800 nm||最小値||11||%|
|at 800 nm||最小値||71||mA/W|
|[陽極特性] 放射感度 *2||最大量子効率感度波長時||最小値||4.2 × 104||A/W|
|標準値||9.5 × 104||A/W|
|at 800 nm||最小値||4.3 × 104||A/W|
|標準値||9.7 × 104||A/W|
|[陽極特性] 暗電流 *2 *3||標準値||4||nA|
|[陽極特性] ゲイン *3||最小値||6.0 × 105||-|
|標準値||1.0 × 106||-|
|リップル/ノイズ (peak to peak) *2 *4||最大値||0.6||mV|
|動作周囲温度 *6||+5 ～ +35||℃|
|保存温度 *6||-20 ～ +50||℃|
*1 入力電圧 ±15 V、コントロール電圧 +0.8 V、保護回路動作直後
*2 コントロール電圧 +0.8 V
*4 負荷抵抗1 MΩ、負荷容量22 pF
*5 コントロール電圧を+0.9 Vから+0.5 Vへ変化させたときの安定時間
