|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||375 nm|
|[最大定格] 陽極－陰極間電圧||1500 V|
|[最大定格] 平均陽極電流||0.03 mA|
|陽極－陰極間 印加電圧||1250 V|
|[陰極特性] ルーメン感度 Min.||25 μA/lm|
|[陰極特性] ルーメン感度 Typ.||40 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||5.5|
|[陰極特性] 放射感度 Typ.||50 mA/W|
|[陽極特性] ルーメン感度 Min.||50 A/lm|
|[陽極特性] ルーメン感度 Typ.||200 A/lm|
|[陽極特性] 放射感度 Typ.||2.5 x 105 A/W|
|[陽極特性] ゲイン Typ.||5.0 x 106|
|[陽極特性] 暗電流(30分後) Typ.||0.5 nA|
|[陽極特性] 暗電流(30分後) Max.||4 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2.2 ns|
|[時間特性] 走行時間 (T.T.) Typ.||22 ns|
