|感度波長 (Short)||160 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||3500 V|
|[最大定格] 平均陽極電流||0.2 mA|
|陽極－陰極間 印加電圧||3000 V|
|[陰極特性] ルーメン感度 Min.||60 μA/lm|
|[陰極特性] ルーメン感度 Typ.||80 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||10|
|[陰極特性] 放射感度 Typ.||80 mA/W|
|[陽極特性] ルーメン感度 Min.||50 A/lm|
|[陽極特性] ルーメン感度 Typ.||200 A/lm|
|[陽極特性] 放射感度 Typ.||2.0 x 105 A/W|
|[陽極特性] ゲイン Typ.||2.5 x 106|
|[陽極特性] 暗電流(30分後) Typ.||100 nA|
|[陽極特性] 暗電流(30分後) Max.||800 nA|
|[時間特性] 上昇時間 (Tr) Typ.||0.7 ns|
|[時間特性] 走行時間 (T.T.) Typ.||16 ns|
