|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||1800 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1700 V|
|[陰極特性] ルーメン感度 Min.||70 μA/lm|
|[陰極特性] ルーメン感度 Typ.||115 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||11|
|[陰極特性] 放射感度 Typ.||88 mA/W|
|[陽極特性] ルーメン感度 Min.||100 A/lm|
|[陽極特性] ルーメン感度 Typ.||200 A/lm|
|[陽極特性] 放射感度 Typ.||1.5 x 105 A/W|
|[陽極特性] ゲイン Typ.||1.7 x 106|
|[陽極特性] 暗電流(30分後) Typ.||10 nA|
|[陽極特性] 暗電流(30分後) Max.||300 nA|
|[時間特性] 上昇時間 (Tr) Typ.||1.3 ns|
|[時間特性] 走行時間 (T.T.) Typ.||14 ns|
