|感度波長 (Short)||185 nm|
|感度波長 (Long)||700 nm|
|感度波長 (Peak)||400 nm|
|[最大定格] 陽極－陰極間電圧||1100 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||80 μA/lm|
|[陰極特性] ルーメン感度 Typ.||105 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||13.5|
|[陰極特性] 放射感度 Typ.||110 mA/W|
|[陽極特性] ルーメン感度 Min.||80 A/lm|
|[陽極特性] ルーメン感度 Typ.||210 A/lm|
|[陽極特性] ゲイン Typ.||2.0 x 106|
|[陽極特性] 暗電流(30分後) Typ.||1 nA|
|[陽極特性] 暗電流(30分後) Max.||10 nA|
|[時間特性] 上昇時間 (Tr) Typ.||0.57 ns|
|[時間特性] 走行時間 (T.T.) Typ.||2.7 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||0.2 ns|
