|受光面サイズ||10 x 24 mm|
|感度波長 (Short)||185 nm|
|感度波長 (Long)||710 nm|
|感度波長 (Peak)||410 nm|
|[最大定格] 陽極－陰極間電圧||1250 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||60 μA/lm|
|[陰極特性] ルーメン感度 Typ.||100 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||8|
|[陰極特性] 放射感度 Typ.||70 mA/W|
|[陽極特性] ルーメン感度 Min.||500 A/lm|
|[陽極特性] ルーメン感度 Typ.||1000 A/lm|
|[陽極特性] 放射感度 Typ.||7.0 x 105 A/W|
|[陽極特性] ゲイン Typ.||1.0 x 107|
|[時間特性] 上昇時間 (Tr) Typ.||1.2 ns|
|[時間特性] 走行時間 (T.T.) Typ.||22 ns|
|備考||陽極ダークカウント(Typ.) ：10 (s-1) 陽極ダークカウント(Max.) : 50 (s-1)|
