|推奨使用（X線感度）範囲||約25 kV～90 kV*1|
|X線検出エリア||220.2 mm（H）× 6.1 mm（V）*2|
|対応ラインスピード||0.178 m/分 ～ 6.073 m/分|
|TDI ラインレート||1×1： 最大 2.109 kHz（6.073 m/分）
ビニング2×2： 最大 1.858 kHz（10.702 m/分）
|制御インターフェース||Camera Link Base Configuration|
|出力信号 （画像データ）||16 bitデジタル出力|
|ピクセルクロック||16.0 MHz（Camera Link）|
|電源||DC +15 V|
