|感度波長 (Short)||300 nm|
|感度波長 (Long)||650 nm|
|感度波長 (Peak)||420 nm|
|[最大定格] 陽極－陰極間電圧||1250 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||60 μA/lm|
|[陰極特性] ルーメン感度 Typ.||90 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||10.5|
|[陰極特性] 放射感度 Typ.||85 mA/W|
|[陽極特性] ルーメン感度 Min.||90 A/lm|
|[陽極特性] ルーメン感度 Typ.||180 A/lm|
|[陽極特性] 放射感度 Typ.||1.7 x 105 A/W|
|[陽極特性] ゲイン Typ.||2.0 x 106|
|[時間特性] 上昇時間 (Tr) Typ.||1.5 ns|
|[時間特性] 走行時間 (T.T.) Typ.||17 ns|
