S13240/S13241シリーズ、 S10140/S10141シリーズ (-01)は、微弱光検出用に開発された裏面入射型FFT-CCDエリアイメージセンサです。ビニング動作を行うことにより、受光面が垂直方向に長いリニアイメージセンサとして使用できるため、分光光度計の検出器に適しています。ビニング動作は、外部回路で信号をデジタル的に加算する従来の方法と比べると、S/Nや信号処理速度において非常に優れています。本製品は、低ノイズ・低暗電流 (MPPモード動作)を特長としていますので、蓄積時間を長くすることで、微弱光の検出が可能となります。その上、従来品 (S10140/S10141シリーズ)に対し飽和電荷量を大きくすることで、広いダイナミックレンジを達成しています。S13240/S13241シリーズは高速読み出しタイプで、S10140/S10141シリーズ (-01)は低ノイズタイプです。画素サイズは12 × 12 μmで、受光面サイズは24.576 (H) × 1.464 (V) mm2 (2048 × 122画素)から24.576 (H) × 6.072 (V) mm2 (2048 × 506画素)までラインアップしています。
|イメージサイズ||24.576 x 3.000 mm|
|有効画素数||2048 x 250 pixels|
|画素サイズ||12 x 12 μm|
|ラインレート typ.||539 ライン/s|
|ラインレート max.||1204 ライン/s|
|暗電流 typ.||30 e-/pixel/s|
|読み出しノイズ typ.||30 e- rms|
|測定条件||指定のない場合はTyp. Ta=25 ℃, フレームレート: フルラインビニング時, 暗電流: MPPモード|
