|受光面サイズ||8 x 24 mm|
|感度波長 (Short)||185 nm|
|感度波長 (Long)||900 nm|
|感度波長 (Peak)||450 nm|
|[最大定格] 陽極－陰極間電圧||1250 V|
|[最大定格] 平均陽極電流||0.1 mA|
|陽極－陰極間 印加電圧||1000 V|
|[陰極特性] ルーメン感度 Min.||375 μA/lm|
|[陰極特性] ルーメン感度 Typ.||450 μA/lm|
|[陰極特性] 青感度指数 （CS 5-58） Typ.||12.5|
|[陰極特性] 赤感度比 （R-68） Typ.||0.4|
|[陰極特性] 放射感度 Typ.||85 mA/W|
|[陽極特性] ルーメン感度 Min.||1000 A/lm|
|[陽極特性] ルーメン感度 Typ.||4500 A/lm|
|[陽極特性] 放射感度 Typ.||8.5 x 105 A/W|
|[陽極特性] ゲイン Typ.||1.0 x 107|
|[陽極特性] 暗電流(30分後) Typ.||10 nA|
|[陽極特性] 暗電流(30分後) Max.||50 nA|
|[時間特性] 上昇時間 (Tr) Typ.||2.2 ns|
|[時間特性] 走行時間 (T.T.) Typ.||22 ns|
|[時間特性] 走行時間拡がり (T.T.S) Typ.||1.2 ns|
