UVtron®:炎・放電センサは、金属の光電効果とガス増倍効果を利用した紫外線ON-OFFセンサです。感度波長範囲は185 nm~260 nmと、紫外域のみに感度を有しているため、半導体光センサなどのように光学的可視光カットフィルタを使う必要がなく、簡単に使用できます。
水素は製造・輸送・貯蔵・利用の各工程において、安全性確保を目的とした水素炎検知・水素炎監視が必要となります。
水素炎は目視での確認が困難であり、また従来の赤外線センサやフレームロッドなどでの高感度検出が難しいため、検知・監視に適した高性能なセンサが求められています。
石油・天然ガスなどの化学燃料
製鉄所・化学工場などからの副産物
自然エネルギー
バイオマス
トラック
船
パイプライン
貯蔵庫
燃料電池自動車
水素ステーション
水素ボイラー
水素発電
浜松ホトニクスが提案するUVtron® 紫外線センサは、水素炎から放出される微弱な紫外線に対して高い感度を有しているため、正確かつ高速な検知を可能にします。
水素炎からの微弱な紫外線を正確に検知します。約10 m離れた水素バーナーの炎も検知可能です。長距離対応を可能にするとともに、設置場所の自由度が高まります。
UVtron®は可視域および太陽光からの紫外線に対して感度がないソーラブラインド特性を有しており、光学的可視光カットフィルタなどを使用する必要がありません。屋内のみならず、屋外での使用にも適しています。
数ms以下での即時検出・即時信号出力が可能なため、点火の際の水素炎を検出します。また、熱などによって間接的に検知する他方式では難しかった水素炎の立ち消えを瞬時に見つけ出すことも可能なため、高い安全管理と迅速な事後対応に貢献します。
